AFK and AFS terminal range
The AFK / AFS terminal series covers 1.5 mm, 2.8 mm and 4.8–6.3 mm blades. The illustrated range includes AFK 1.5, AFK 2.8, AFK 4.8, AFS 1.5, AFS 2.8 and AFS 4.8. Its compact design, low mating forces and retention suit high-density connector designs.
The Lear AFK / AFS terminal series combines a high-performance copper-alloy contact body with a stainless-steel support spring to maintain stable contact pressure and reliable electrical performance. Two integrated latches secure each terminal inside the connector housing, while a four-sided secondary-lock interface provides additional retention and helps prevent terminal displacement.
The terminal range supports wire cross-sections up to 6 mm² and is available with tin, gold and silver plating to address different electrical and environmental requirements. Versions for both sealed and unsealed connector systems enable use across a wide range of automotive electrical architectures.
Key technical features and benefits:
- High-performance copper-alloy contact body
- Stainless-steel spring supporting the contact area
- Stable contact pressure and reliable electrical performance
- Two latches for primary terminal locking and retention
- Four-sided secondary-lock provision
- Wire cross-sections up to 6 mm²
- Tin-, gold- and silver-plated versions available
- Suitable for sealed and unsealed connector applications
- Supports connector systems with high terminal density
- Compatible with common industry interface requirements
- Robust terminal retention for demanding automotive environments
