TECHNICAL INFORMATION
Identification
- Product Category
- CONNECTORS
- Part Number
- E37112300
- Product Family
- AFK
Other properties
- No. of cavities
- 4
- Terminal Type
- Receptacle
- Terminal Size [mm]
- 1.5
- Sealable
- Unsealed
- Color
- BLACK
- Connector Application
- Inline
2D Drawing
2D Drawing E37112300
4way AFS 1.5 Tab Unsealed Black Connector
E51716200
Product Category:
CONNECTORSLegacy Part Number:
–No. of cavities
4
Product Family
AFS
Terminal Size [mm]
1.5
Sealable
Unsealed
AFK 1.5 Receptacle Sealed Crimp Terminal, Sn, 0.2-0.35mm²
E40928100
Product Category:
TERMINALSLegacy Part Number:
–Terminal Size [mm]
1.5
Minimum Cable Cross section [mm²]
0.2
Maximum Cable Cross section [mm²]
0.35
AFK 1.5 Receptacle Unsealed Crimp Terminal, Sn, 0.2-0.35mm²
3202531A5
Product Category:
TERMINALSLegacy Part Number:
26591331185Terminal Size [mm]
1.5
Minimum Cable Cross section [mm²]
0.2
Maximum Cable Cross section [mm²]
0.35
AFK 1.5 Receptacle Unsealed Crimp Terminal, Sn, 0.2-0.35mm²
E26574100
Product Category:
TERMINALSLegacy Part Number:
26591000001Terminal Size [mm]
1.5
Minimum Cable Cross section [mm²]
0.2
Maximum Cable Cross section [mm²]
0.35
AFK 1.5 Receptacle Unsealed Crimp Terminal, Sn, 0.5-1mm²
3202650K8
Product Category:
TERMINALSLegacy Part Number:
26592331185Terminal Size [mm]
1.5
Minimum Cable Cross section [mm²]
0.5
Maximum Cable Cross section [mm²]
1
AFK 1.5 Receptacle Unsealed Crimp Terminal, Sn, 0.5-1mm²
E26574000
Product Category:
TERMINALSLegacy Part Number:
26592000001Terminal Size [mm]
1.5
Minimum Cable Cross section [mm²]
0.5
Maximum Cable Cross section [mm²]
1
E37112300 - 4way AFK 1.5 Receptacle Unsealed Black Connector
Part Number: E37112300
Product Specification
This unsealed receptacle connector features 4 cavities and belongs to the AFK product family within the Connectors category. It accommodates 1.5 mm terminals.
Primarily designed for inline applications in automotive vehicles.
The main connector part is molded in PBT with a dominant black color.
Part Number: E37112300.
This product requires other components for a fully functional assembly configuration:
- 4way AFS 1.5 Tab Unsealed Black Connector (E51716200)
- AFK 1.5 Receptacle Sealed Crimp Terminal, Sn, 0.2-0.35mm² (E40928100)
- AFK 1.5 Receptacle Unsealed Crimp Terminal, Sn, 0.2-0.35mm² (3202531A5)
- AFK 1.5 Receptacle Unsealed Crimp Terminal, Sn, 0.2-0.35mm² (E26574100)
- AFK 1.5 Receptacle Unsealed Crimp Terminal, Sn, 0.5-1mm² (3202650K8)
- AFK 1.5 Receptacle Unsealed Crimp Terminal, Sn, 0.5-1mm² (E26574000)
