TECHNICAL INFORMATION

Identification

Product Category
SEALS
Part Number
32195X0K4
Legacy Part Number
17706000000

Other properties

Seal type
Wire Seal Cap
Cable diam min [mm]
5.6
Cable diam max [mm]
5.9

2D Drawing

2D Drawing 32195X0K4

DOWNLOAD
1way MAK 12 Receptacle Sealed Black Connector with CPA, Code A
1way MAK 12 Receptacle Sealed Black Connector with CPA, Code A
E05685100
Product Category:
CONNECTORS
Legacy Part Number:
19623000001
No. of cavities
1
Product Family
MAK
Terminal Size [mm]
12
Sealable
Sealed

32195X0K4 - Wire Seal Cap

Part Number: 32195X0K4

Wire Seal Cap

Product Specification

Previously cataloged under part number 17706000000.

A wire sealing cap that provides environmental protection at the cable entry point of an occupied connector cavity. Its two-component (2K) design combines effective sealing performance with enhanced cable support. The integrated rigid plastic element reinforces strain relief and cable retention, particularly for larger wire cross-sections.

Constructed from VMQ and PBT-GF10, it accepts cable insulation diameters from 5.6 mm to 5.9 mm.

Part Number: 32195X0K4.

This product requires other components for a fully functional assembly configuration:
