TECHNICAL INFORMATION
Identification
- Product Category
- CONNECTORS
- Part Number
- E53024100
- Product Family
- MSK
Other properties
- No. of cavities
- 2
- Terminal Type
- Tab
- Terminal Size [mm]
- 0.63
- Sealable
- Unsealed
- Color
- BLACK
- Connector Application
- Inline
2D Drawing
2D Drawing E53024100
2way MSK 0.63 Receptacle Unsealed Black Connector
E51714700
Product Category:
CONNECTORSLegacy Part Number:
–No. of cavities
2
Product Family
MSK
Terminal Size [mm]
0.63
Sealable
Unsealed
COS 0.63 Tab Unsealed Crimp Terminal, Sn, 0.22-0.35mm²
E37600300
Product Category:
TERMINALSLegacy Part Number:
–Terminal Size [mm]
0.63
Minimum Cable Cross section [mm²]
0.22
Maximum Cable Cross section [mm²]
0.35
COS 0.63 Tab Unsealed Crimp Terminal, Au, 0.22-0.35mm²
E56934100
Product Category:
TERMINALSLegacy Part Number:
–Terminal Size [mm]
0.63
Minimum Cable Cross section [mm²]
0.22
Maximum Cable Cross section [mm²]
0.35
COS 0.63 Tab Unsealed Crimp Terminal, Sn, 0.5-0.75mm²
E37600400
Product Category:
TERMINALSLegacy Part Number:
–Terminal Size [mm]
0.63
Minimum Cable Cross section [mm²]
0.5
Maximum Cable Cross section [mm²]
0.75
COS 0.63 Tab Unsealed Crimp Terminal, Au, 0.5-0.75mm²
E56934400
Product Category:
TERMINALSLegacy Part Number:
–Terminal Size [mm]
0.63
Minimum Cable Cross section [mm²]
0.5
Maximum Cable Cross section [mm²]
0.75
E53024100 - 2way MSK 0.63 Tab Unsealed Black Connector
Part Number: E53024100
Product Specification
This 2-way unsealed connector belongs to the MSK product family within the Connectors category, accommodating Tab terminals sized at 0.63 mm.
Primarily designed for inline applications in automotive vehicles.
The main connector part is molded in PBT GF with a dominant black color.
Part Number: E53024100.
This product requires other components for a fully functional assembly configuration:
- 2way MSK 0.63 Receptacle Unsealed Black Connector (E51714700)
- COS 0.63 Tab Unsealed Crimp Terminal, Sn, 0.22-0.35mm² (E37600300)
- COS 0.63 Tab Unsealed Crimp Terminal, Au, 0.22-0.35mm² (E56934100)
- COS 0.63 Tab Unsealed Crimp Terminal, Sn, 0.5-0.75mm² (E37600400)
- COS 0.63 Tab Unsealed Crimp Terminal, Au, 0.5-0.75mm² (E56934400)
