TECHNICAL INFORMATION
Identification
- Product Category
- EYELETS
- Part Number
- E08971500
- Legacy Part Number
- 110634-AK17
Other properties
- Connection Technology
- Standard Crimp
- Thread Diameter [mm]
- M8
- No. of wire connections
- 1
- Minimum Cable Cross section [mm²]
- 3.5
- Maximum Cable Cross section [mm²]
- 13
- Ring diameter inside [mm]
- 8.76
- Core Material
- CuZn
- Plating Material
- Sn
- Remarks
- Post plated
- RoHS
- YES
