TECHNICAL INFORMATION
Identification
- Product Category
- EYELETS
- Part Number
- 3201514A8
- Legacy Part Number
- 25231212179
Other properties
- Connection Technology
- Standard Crimp
- Thread Diameter [mm]
- M5
- Special feature for connection area
- Round Hole
- No. of wire connections
- 3
- Minimum Cable Cross section [mm²]
- 4
- Maximum Cable Cross section [mm²]
- 6
- Ring diameter inside [mm]
- 5.3
- Core Material
- CuSn
- Plating Material
- Sn
DOWNLOADS
SIMILAR PARTS
RING TERMINAL M5
Part Number: 320151F71
Product Category: EYELETS
Legacy Part Number: 25231123011
Minimum Cable Cross section [mm²]
4
Maximum Cable Cross section [mm²]
6
Thread Diameter [mm]
M5
RING TERMINAL M5
Part Number: 320151F9V
Product Category: EYELETS
Legacy Part Number: 25231123009
Minimum Cable Cross section [mm²]
4
Maximum Cable Cross section [mm²]
6
Thread Diameter [mm]
M5
RING TERMINAL M4
Part Number: E01851600
Product Category: EYELETS
Legacy Part Number: 25229212179
Minimum Cable Cross section [mm²]
4
Maximum Cable Cross section [mm²]
6
Thread Diameter [mm]
M4
Loading...
3201514A8 - RING TERMINAL M5
Part Number: 3201514A8
Click to see 3D model
Product Specification
Lear’s Eyelet product portfolio includes a wide spectrum of standard and customized ring terminal solutions.
Several Eyelet types and customized configuration possibilities enable to find the best solution for a broad range of automotive applications.
Part Number: 3201514A8.
