TECHNICAL INFORMATION
Identification
- Product Category
- CONNECTORS
- Part Number
- 3216647W5
- Legacy Part Number
- 16954669696
- Product Family
- AFK
Other properties
- No. of cavities
- 6
- Terminal Type
- Receptacle
- Terminal Size [mm]
- 1.5
- Sealable
- Unsealed
- Fixation feature
- NO
- Color
- BLACK
AFK 1.5 Receptacle Unsealed Crimp Terminal, Sn, 0.2-0.35mm²
3202531A5
Product Category:
TERMINALSLegacy Part Number:
26591331185Terminal Size [mm]
1.5
Minimum Cable Cross section [mm²]
0.2
Maximum Cable Cross section [mm²]
0.35
AFK 1.5 Receptacle Unsealed Crimp Terminal, Au, 0.2-0.35mm²
3202585G7
Product Category:
TERMINALSLegacy Part Number:
26591201702Terminal Size [mm]
1.5
Minimum Cable Cross section [mm²]
0.2
Maximum Cable Cross section [mm²]
0.35
AFK 1.5 Receptacle Unsealed Crimp Terminal, Sn, 0.5-1mm²
3202650K8
Product Category:
TERMINALSLegacy Part Number:
26592331185Terminal Size [mm]
1.5
Minimum Cable Cross section [mm²]
0.5
Maximum Cable Cross section [mm²]
1
Loading...
3216647W5 - 6way AFK 1.5 Receptacle Unsealed Black Connector
Part Number: 3216647W5
Click to see 3D model
Product Specification
Previously cataloged under part number 16954669696.
This connector belongs to the AFK product family within the CONNECTORS category, configured as a 6-cavity receptacle. It is unsealed and accommodates 1.5 mm terminals.
No connector-to-body fixation feature is incorporated. The main connector part is molded in PBT with a dominant black color.
Part Number: 3216647W5.
This product requires other components for a fully functional assembly configuration:
