TECHNICAL INFORMATION
Identification
- Product Category
- CONNECTORS
- Part Number
- E51716500
- Product Family
- AFK
Other properties
- No. of cavities
- 10
- Terminal Type
- Receptacle
- Terminal Size [mm]
- 2.8
- Sealable
- Unsealed
- Color
- BLACK
2D Drawing
2D Drawing E51716500
AFK 2.8 Receptacle Unsealed Crimp Terminal, Sn, 0.2-0.35mm²
3202536L6
Product Category:
TERMINALSLegacy Part Number:
26700201185Terminal Size [mm]
2.8
Minimum Cable Cross section [mm²]
0.2
Maximum Cable Cross section [mm²]
0.35
AFK 2.8 Receptacle Unsealed Crimp Terminal, Sn, 0.5-1mm²
3202581Y9
Product Category:
TERMINALSLegacy Part Number:
26701201185Terminal Size [mm]
2.8
Minimum Cable Cross section [mm²]
0.5
Maximum Cable Cross section [mm²]
1
AFK 2.8 Receptacle Unsealed Crimp Terminal, Sn, 0.5-1mm²
E26574300
Product Category:
TERMINALSLegacy Part Number:
26701000001Terminal Size [mm]
2.8
Minimum Cable Cross section [mm²]
0.5
Maximum Cable Cross section [mm²]
1
AFK 2.8 Receptacle Unsealed Crimp Terminal, Sn, 1.5-2.5mm²
3202581I7
Product Category:
TERMINALSLegacy Part Number:
26705201185Terminal Size [mm]
2.8
Minimum Cable Cross section [mm²]
1.5
Maximum Cable Cross section [mm²]
2.5
AFK 2.8 Receptacle Unsealed Crimp Terminal, Sn, 1.5-2.5mm²
E26574400
Product Category:
TERMINALSLegacy Part Number:
26705000001Terminal Size [mm]
2.8
Minimum Cable Cross section [mm²]
1.5
Maximum Cable Cross section [mm²]
2.5
E51716500 - 10way AFK 2.8 Receptacle Unsealed Black Connector
Part Number: E51716500
Product Specification
This product belongs to the CONNECTORS category within the AFK product family. It is an unsealed receptacle connector configured with 10 cavities, accommodating 10 circuits.
Designed for use with 2.8 mm terminals, the connector accepts receptacle terminal types across all 10 ways.
The main connector part is molded in PBT with a dominant black color.
Part Number: E51716500.
This product requires other components for a fully functional assembly configuration:
- AFK 2.8 Receptacle Unsealed Crimp Terminal, Sn, 0.2-0.35mm² (3202536L6)
- AFK 2.8 Receptacle Unsealed Crimp Terminal, Sn, 0.5-1mm² (3202581Y9)
- AFK 2.8 Receptacle Unsealed Crimp Terminal, Sn, 0.5-1mm² (E26574300)
- AFK 2.8 Receptacle Unsealed Crimp Terminal, Sn, 1.5-2.5mm² (3202581I7)
- AFK 2.8 Receptacle Unsealed Crimp Terminal, Sn, 1.5-2.5mm² (E26574400)
