TECHNICAL INFORMATION
Identification
- Product Category
- CONNECTORS
- Part Number
- 32165K2MA
- Legacy Part Number
- 13559562699
- Product Family
- AFK
Other properties
- No. of cavities
- 5
- Terminal Type
- Receptacle
- Terminal Size [mm]
- 2.8, 4.8
- Sealable
- Unsealed
- Color
- BLACK
2D Drawing
2D Drawing 32165K2MA
AFK 2.8 Receptacle Unsealed Crimp Terminal, Sn, 0.2-0.35mm²
3202536L6
Product Category:
TERMINALSLegacy Part Number:
26700201185Terminal Size [mm]
2.8
Minimum Cable Cross section [mm²]
0.2
Maximum Cable Cross section [mm²]
0.35
AFK 2.8 Receptacle Unsealed Crimp Terminal, Sn, 0.5-1mm²
3202581Y9
Product Category:
TERMINALSLegacy Part Number:
26701201185Terminal Size [mm]
2.8
Minimum Cable Cross section [mm²]
0.5
Maximum Cable Cross section [mm²]
1
AFK 2.8 Receptacle Unsealed Crimp Terminal, Sn, 1.5-2.5mm²
3202581I7
Product Category:
TERMINALSLegacy Part Number:
26705201185Terminal Size [mm]
2.8
Minimum Cable Cross section [mm²]
1.5
Maximum Cable Cross section [mm²]
2.5
AFK 4.8/6.3 Receptacle Unsealed Crimp Terminal, Sn, 0.2-0.35mm²
320257AU0
Product Category:
TERMINALSLegacy Part Number:
26697330186Terminal Size [mm]
4.8, 6.3
Minimum Cable Cross section [mm²]
0.2
Maximum Cable Cross section [mm²]
0.35
AFK 4.8/6.3 Receptacle Unsealed Crimp Terminal, Sn, 0.5-1mm²
3202537J9
Product Category:
TERMINALSLegacy Part Number:
26649330186Terminal Size [mm]
4.8, 6.3
Minimum Cable Cross section [mm²]
0.5
Maximum Cable Cross section [mm²]
1
AFK 4.8/6.3 Receptacle Unsealed Crimp Terminal, Sn, 1.5-2.5mm²
3202537M3
Product Category:
TERMINALSLegacy Part Number:
26648330186Terminal Size [mm]
4.8, 6.3
Minimum Cable Cross section [mm²]
1.5
Maximum Cable Cross section [mm²]
2.5
AFK 4.8/6.3 Receptacle Unsealed Crimp Terminal, Sn, 2.5-4mm²
320257BP2
Product Category:
TERMINALSLegacy Part Number:
26650330186Terminal Size [mm]
4.8, 6.3
Minimum Cable Cross section [mm²]
2.5
Maximum Cable Cross section [mm²]
4
32165K2MA - 5way AFK Receptacle Unsealed Black Connector
Part Number: 32165K2MA
Product Specification
Previously cataloged under part number 13559562699.
This connector belongs to the AFK product family within the Connectors category. It is an unsealed receptacle configuration offering 5 cavities.
The main connector part is molded in PA66 with a dominant black color.
Part Number: 32165K2MA.
This product requires other components for a fully functional assembly configuration:
- AFK 2.8 Receptacle Unsealed Crimp Terminal, Sn, 0.2-0.35mm² (3202536L6)
- AFK 2.8 Receptacle Unsealed Crimp Terminal, Sn, 0.5-1mm² (3202581Y9)
- AFK 2.8 Receptacle Unsealed Crimp Terminal, Sn, 1.5-2.5mm² (3202581I7)
- AFK 4.8/6.3 Receptacle Unsealed Crimp Terminal, Sn, 0.2-0.35mm² (320257AU0)
- AFK 4.8/6.3 Receptacle Unsealed Crimp Terminal, Sn, 0.5-1mm² (3202537J9)
- AFK 4.8/6.3 Receptacle Unsealed Crimp Terminal, Sn, 1.5-2.5mm² (3202537M3)
- AFK 4.8/6.3 Receptacle Unsealed Crimp Terminal, Sn, 2.5-4mm² (320257BP2)
